Electrical Safety Audit – Thermography Test


Click to view On large


Thermal Scanning is helps us to visualize and quantify changes in the surface temperature of electrical Switchgear. An infrared camera converts infrared radiation (heat) emitted from the surface of electrical equipment into electrical impulses. These impulses are Spotted as colours which represent the various temperatures. Thermal Imaging identifies equipment flaws and pinpoints any hot spots often invisible to the naked eye.



When parts of your electrical systems begin to have problems, they give off heat – usually a sign of electrical resistance or excessive friction. Abnormal temperatures can be seen easily.


Before an electrical component burns up, it heats up. Early detection with Infrared Thermal Scanning detects growing problems before they cause a system failure or fire. Maintenance personnel can correct the problem before the component fails.


INFRARED THERMOGRAPHY IS USED TO PERFORM INSPECTIONS ON ELECTRICAL EQUIPMENT BECAUSE EXCESS RESISTANCE ON ELECTRICAL APPARATUS INDICATES ELECTRICAL FAULTS SUCH AS :

  • Loose connections
  • Overloads
  • Imbalanced circuits
  • Faulty Equipment
  • Damaged switches
  • Faulty fuses


THERMAL SCANNING IMPROVES THE SAFETY OF THE ASSET UNDER YOUR CONTROL. THERMAL IMAGING SHOULD BE USED AS A VEHICLE TO FACILITATE EARLY DETECTION OF EQUIPMENT FAILURE :

  • Ensures a higher level of plant safety
  • Reduces the possibility of fire
  • Reduces the chance of critical downtime
  • Reduces the possibility of loss of production
